3 Axles 25tons LPG Mobile Tanker Trailer 49600L Liquefied Petroleum Gas Tank Trailer
Product Description
1) LPG Bridger Truck Tanker Trailer is used to transport liquid petroleum gas in large quantity and in long distance from depot or terminal station to smaller lpg stations in other cities.We can offer lpg bridger truck tanker trailers from 40cbm to 60cbm and from 20tons to 30tons.
2) Manufacturing standards of lpg bridger truck tanker trailers : GB-150, ASME, U STAMP, CCC, ISO9001 : 2008
3) Optional accessories of lpg bridger truck tanker trailers:ROCHESTER level gauge,flow meter,sunshelter,lpg pump,lpg dispenser machine,filling hose
4) Available tanker trailer capacity of lpg bridger truck tanker trailers : 18mt,18t,20mt,20tons,22mt,22tons,25mt,25tons,30mt,30tons
Specification
| Tanker Essential Information |
| Volume of Tank (cbm) |
49.6 |
| Overall Dimensions(L*W*H)(mm) |
12740*2480*3800 |
| Tank Dimensions(Inner Diameter*thickness*Length) |
2300*12*12354 |
| Estimated Tare Weight (kg) |
15300 |
| Payload(kg) |
20832 |
| Total Weight(kg) |
36132 |
| Wheelbase(mm) |
6800+1320+1320 |
| Shell of Tanker |
| Products |
Liquefied Petroleum Gas (propane) |
| Fluid Property |
Flammable |
| Design Temperature(ºC) |
50ºC |
| Design Pressure(MPa) |
1.61 |
| Corrosion Allowance(mm) |
1.00 |
| Weld Joint Factor |
1 |
| Major Materials of Bearing Pressure |
Tanker body:Q345,12mm, |
| End plate:Q345R,12mm |
| Main beam:16Mn |
| Detection |
| Heat Treatment |
Overall treatment in a furnace,600ºC to 640 ºC |
| Flaw Detection |
100% Flaw detection |
| Test Pressure(MPa) |
1.61 |
| Hydraulic Test(MPa) |
2.1 |
| Magnaflux Inspection |
Aim at welding place that flaw detection can not cover |
| Manhole (As Customer's Requirement) |
| Quantity |
1;on top |
| Size |
DN450 |
| Safety Valve(As Customer's Requirement) |
| Quantity |
2 |
| Location |
On the top of tanker |
| Size |
DN80 |
| Level Gauge |
| Type |
Manuel Switch type |
| Location |
At the rear of the end dish |
| Running System |
| Axles |
3*13T BPW |
| Tire |
12R22.5 Tubeless tire ,8 with one spare tire |
| Landing leg |
JOST |
| King Pin |
#50 or #90 |
| Control System |
| Emergency Cut-off Valves |
2 or 3 |
| Ball Valve |
4 or 6 |
| Liquid Gauge |
1 |
| Pressure Indicating Thermometer |
1 |
| Pressure Gage |
1 |
FAQ
Q1: What kinds of LPG products I can order from your company?
A: We specialize in producing 5CBM to 200CBM LPG above ground storage tanker, 5CBM to 120CBM LPG underground storage tank, 5CBM to 38.5CBM LPG tank truck, 5CBM to 25.5CBM LPG dispenser truck/LPG bobtail truck, 40CBM to 61.9CBM LPG semi trailer and 5CBM to 50CBM LPG Skid Station/LPG mobile filling station etc. Please feel free to contact us for details.
Q2: What is your production standard of LPG products? Can you manufacture your products under ASME standard?
A: Usually our LPG products adopts GB-150/China standard, there ASME standard for optional. Yes, we can do ASME standard and our ASME standard as per DIV 01 SEC VIII.
Q3: Have you supplied LPG products to any renowned companies?
A: Our group company is a regular strategic partner of some big gas companies. We have supplied many storage tanks and semi trailer for them with different sizes,such as ENOC,AARANO,NIPCO,LAKEGAS...The biggest size tank we ever provided is 200m3 LPG storage tanks,.
