HUBEI CHENGLI SPECIAL AUTOMOBILE CO,.LTD
Dom Produktyciężarówka dostawcza paliwa

ISUZU 12000L 12CBM Aluminum Alloy Aircraft Refueling Trucks

Chiny HUBEI CHENGLI SPECIAL AUTOMOBILE CO,.LTD Certyfikaty
Chiny HUBEI CHENGLI SPECIAL AUTOMOBILE CO,.LTD Certyfikaty
Im Online Czat teraz

ISUZU 12000L 12CBM Aluminum Alloy Aircraft Refueling Trucks

ISUZU 12000L 12CBM Aluminum Alloy Aircraft Refueling Trucks
ISUZU 12000L 12CBM Aluminum Alloy Aircraft Refueling Trucks ISUZU 12000L 12CBM Aluminum Alloy Aircraft Refueling Trucks ISUZU 12000L 12CBM Aluminum Alloy Aircraft Refueling Trucks ISUZU 12000L 12CBM Aluminum Alloy Aircraft Refueling Trucks

Duży Obraz :  ISUZU 12000L 12CBM Aluminum Alloy Aircraft Refueling Trucks

Szczegóły Produktu:

Miejsce pochodzenia: Suizhou, Chiny
Nazwa handlowa: CLW
Orzecznictwo: CCC,ISO,BV,SGS
Numer modelu: CLW5096JYC

Zapłata:

Minimalne zamówienie: 1 jednostka
Cena: negotiable
Szczegóły pakowania: Nagie opakowanie, Ro-ro, statek masowy
Czas dostawy: 30-35 dni
Zasady płatności: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Możliwość Supply: 500 jednostek/miesiąc
Szczegółowy opis produktu
Marka podwozia: Howo, Dongfeng, Isuzu, Foton, JAC itp. Skrzynia biegów: 8 biegów do przodu i 2 biegi wsteczne
Objętość tankowca: 15m3, 16m3, 17m3, 18m3, 19m3, 20m3 itd. Materiał zbiornika: Stal węglowa, ze stali nierdzewnej lub stopu aluminium
Kształt zbiornika: Kwadrat Okrągły, Okrągły Rodzaj oleju transportowego: Olej napędowy, benzyna, benzyna, olej itp.
Pompa oleju: Znana chińska marka dozownik oleju: Znana chińska marka
Bęben na wąż z pistoletem do napełniania: 15 metrów (długość może być dłuższa na żądanie) System odzyskiwania oparów oleju: Fakultatywny
Czas dostawy: 35 dni Kolor: Dostosowane
Gwarancja: 1 rok
Podkreślić:

ISUZU Aircraft Refueling Trucks

,

12000L Aircraft Refueling Trucks

,

12CBM mobile refueling truck

ISUZU 12000L 12CBM Aluminum Alloy Helicopter Fuel Dispenser Refueling Truck




Product Description
1. Purpose: It used for helicopter refueling and mobile transporting aviation kerosene.
2. Main parts: Fuel pump, flow meter and filling gun etc.
3. Advantage: Our helicopter refueling truck have most competitive price.




Product Specification

Truck Specification
Cab ISUZU cab with one sleeper with A/C
Driving Type 4*2 Left hand driving
Max Speed (km/h) 100
Overall dimension(mm) 8840*2450*3000 (mm)
GVW (kg) 19000
Mass in working order (kg) 8900
Wheelbase(mm) 5550
Tire 10.00R20
Clutch Single-plate dry diaphragm spring clutch
Steering Hydraulic steering with power assistance
Gear box 8-speed
Bridge Front axle 6300kg
Rear axle 13000kg
Engine Model 4HK1-TC50 / EURO V
Fuel Type Diesel fuel
Type in line-4,ind-cooler turbocharged
Max output power/rotate speed (hp /rpm ) 205hp
Braking system Service Brake Compressed air brake
Eletric system 24v
Upper-Body specification
Rated Capacity (L) 12000
Tank Material Stainless steel



Reference Photos

ISUZU 12000L 12CBM Aluminum Alloy Aircraft Refueling Trucks 0

ISUZU 12000L 12CBM Aluminum Alloy Aircraft Refueling Trucks 1



Aluminum Alloy Tank Production Process

ISUZU 12000L 12CBM Aluminum Alloy Aircraft Refueling Trucks 2



Other Kinds of Fuel Dispenser Trucks

ISUZU 12000L 12CBM Aluminum Alloy Aircraft Refueling Trucks 3



ISUZU 12000L 12CBM Aluminum Alloy Aircraft Refueling Trucks 4



Sales Service



① Pre-sales Service: Communicate with customers, analyze their needs.
② Sales Service: Provide professional technical solutions, recommend the right models accordingly.
③ After-sales Service: For different products, we can quote the EXW, FOB, CFR or CIF price accordingly.



FAQ

Q1: What kinds of Helicopter refueling truck I can order from your company?

A: We can supply different size helicopter refueling truck as client's request. Basically speaking, we can supply 5CBM to 20CBM type. Pls contact with us for more technical details and discussion.



Q2: What is your production standard of Helicopter Refueling Truck products?

A: China GB local standard.



Q3: Can we adopts International brand fuel pump for helicopter refueling truck?

A: Sure, we already cooperated with many international brand supplier.



Q4: What about warranty?
A: Equipment warranty is 12 months from the date on which the equipment is applied successfully into operation, or 13 months from the date on which the equipment has been delivered, whichever comes first.



Q5: Where is your factory? How far from Shanghai to your factory?
A: Our factory based in Suizhou city, Hubei province, China. Our overseas marketing office in Wuhan. From Shanghai to Wuhan is only 2 hours by airplane. Warmly welcome you to visit us in near future!
