6X2 Dongfeng Frozen Lorry Refrigerated Van Truck with Thermo King Refrigerator
Product Description
1. Purpose of Freezer Van Truck : It used for transporting frozen fish, meat, chicken, duck, fresh vegetable and vaccinum etc.
2. Main parts of Freezer Van Truck : Refrigerating unit and control system.
3. Features of Freezer Van Truck : International chassis brand and International refrigerating unit brand for optional.
4. For the special requirements of freezer vehicle,such as the meat transportation, the meat hook, aluminum alloy guide rail and ventilation slots, ladder, LED lamp, etc. parts can be chosen and installed. Different refrigerated units are available like Carrier, Thermos King, Dongin, Kingtec, etc. The standby battery, side door, side windows, etc are optional.
Freezer truck also called Refrigerated truck, refrigerator truck,refrigerated van truck, refigerated vehicle, freezer truck, cold van, etc.
1. Freezer truck loading capacity :1ton,1.5ton,3ton,5ton,10ton,12ton,15ton,20tons,etc.
2. Freezer truck brand : Foton, 1suzu, Howo, Dongfeng, Jac, Jmc,etc
3. Freezer truck transport : fish, seafood, meat, vegetable, milk, food,fruit, etc.
4.Freezer truck : hot selling in Peru in 2020
Specifications
| Vehicle name |
Refrigerated
truck
|
Truck model |
EQ5250 6x2 Driving |
| G.V.W(Kg) |
25000 |
Body capacity(m3) |
50.5 |
| Load weight(Kg) |
15405,15635 |
Overall dimension
L*W*H(mm)
|
11100×2550×3990 |
| Curb weight(Kg) |
9400,9170 |
Cargo box size(mm) |
8600×2400×2450 |
| Cab passengers |
3, with air conditioner |
|
|
| Approach/departure angle(°) |
23/11 |
Suspension front/rear(mm) |
1430/1870,1430/2270,
1430/2770,1430/2870
|
| Axle load weight front/rear(Kg) |
7000/7000/11000 |
Top speed(Km/h) |
90 |
| Chassis parameters |
| Chassis model |
DFH1250BXV |
Emision standard |
Euro 2-3-4-5 Optional |
| Axle number |
3 |
Tire number |
8 |
| wheelbase (mm) |
1800+4100,1800+5000 |
| Tire size |
10.00-20,10.00R20,295/80R22.5 |
| Leaf spring |
10/10/10+8,10/10/11+8 |
Front wheel tread(mm) |
1915/1915,1955/1955 |
| Fuel sort |
diesel |
Rear wheel tread(mm) |
1860 |
| Engine model |
Engine manufacturer |
displacement(ml) |
power(KW/HP) |
| ISD210 50 |
Dongfeng |
6700 |
155/210 |
Reference photos
Thermo king Independent refrigerator unit MP-4000
Customer Visiting
Our Service
-
Quick feedback to solve your questions
-
Professional engineering and production team
-
Related Accessories and spare parts offered,no future worries
-
Regular customer after-sale visiting
-
Free technical staff training and guidance
-
Reasonable price and good quality
-
Quick delivery and shipment
FAQ
Q1: What loading weight freezer truck I can order from your company?
A: We can supply 990kg-40tons refrigerated truck, if you need big size refrigerated semi trailer, we also can supply it, there have 2 axles and 3 axles 40tons to 60tons refrigerated semil trailer for optional.
Q2: What is your production standard of freezer truck? Whether your refrigerated truck and trailer can export to USA, Canada and Europen countries?
A: Our CBU refrigerated truck and trailerg truck is produced as per China GB local standard; We can export super structure to those market, we ever exported refrigerated truck super structure and refrigerated semi trailer to Europen countries before.
Q3: Can we adopts International brand refrigerating unit for freezer truck and semi trailer?
A: Sure, we can supply USA brand Thermo King, Carrier and South Korea brand DONG IN THERMO.
Q4: What about warranty?
A: Equipment warranty is 12 months from the date on which the equipment is applied successfully into operation, or 13 months from the date on which the equipment has been delivered, whichever comes first.
Q5: Where is your factory? How far from Shanghai to your factory?
A: Our factory based in Suizhou city, Hubei province, China. Our overseas marketing office in Wuhan. From Shanghai to WUhan is only 2 hours by airplane. Warmly welcome you to visit us in near future!
