14000L Water Sprinkler Truck For Transport Water Tank

Duży Obraz : 14000L Water Sprinkler Truck For Transport Water Tank

Szczegóły Produktu:

Miejsce pochodzenia:	Suizhou, Chiny
Nazwa handlowa:	CLW
Orzecznictwo:	CCC,ISO
Numer modelu:	CLW5079dcx

Zapłata:

Minimalne zamówienie:	1 jednostka
Cena:	negotiable
Szczegóły pakowania:	Nagie opakowanie, Ro-ro, statek masowy
Czas dostawy:	20-30 dni
Zasady płatności:	L/C, T/T, D/A, D/P, Western Union, Moneygram
Możliwość Supply:	500 jednostek miesięcznie

Kontakt

Szczegółowy opis produktu

Podwozie ciężarówki:	ISUZU, HOWO, Dongfeng, FAW, JAC, JMC, FOTON	Tworzywo:	Stal węglowa Q235a
Grubość:	bok 4mm, dół 4mm	Paliwo:	Typ silnika wysokoprężnego
Pompa wodna:	Chinowa znana marka	Wysokość ssania:	7m
Zasięg armat:	30m	Szerokość zraszania:	15 m
wideo z operacji:	Tak	Instrukcja obsługi:	Tak
Logo:	Jako żądanie klienta	Gwarancja:	1 rok
Typ cysterny na wodę:	Cysterna do rozpylania wody
Podkreślić:	Dongfeng 14000L Water Sprinkler Truck , Carbon Steel Q235A Water Sprinkler Truck

Dongfeng 14,000L Water Sprinkler Truck for transport water tank

Product Description

1. Optional chassis brand :
Dongfeng, Sinotruk, FOTON/Forland, Faw, Shacaman,JAC,JMC etc
2. Material of portable water truck :
High Tension Steel Q235/Q345,stainless steel 304 for option.
3. Sprinking Width of portable water truck :＞14M
4. Rear working platform with water cannon range of portable water truck :28M
5. Reliable and high quality water pump (Chinese Top brand or Italy Brand)
6. Purpose: water sprinker for road cleaning, drinking water transport

Advanced facilities

mechanics tray,
mechanics pump,
anti-corrosion & rust prevention in the tank,
multi-directional water inlet and outlet joints,
solenoid valves,
pneumatic valves, etc.

Working sence :

roads, trees, green belts, lawns, roads, factories and mines, and high-altitude buildings.

Specifications of 14000 liters water tanker truck

Condition	New condition/Left hand drive/4x2
Chassis	Brand		Dongfeng
	Curb weight(kg)		6660 kg
	Loading weight(kg)		9140 kg
	Gross weight(kg)		15995 kg
	Wheelbase(mm)		4700 mm
	Tank Dimensions(mm)		450022001400 mm
	Front Loading Capacity (Ton)		4.5
	Rear Loading Capacity (Ton)		9
	Max. driving speed(km/h)		90 km/h
	Clutch		Reinforced diaphragm clutch
	Brakes		Service brake: dual circuit compressed air brake Parking brake:(emergency brake): spring energy, compressed air operating on rear wheels
			Auxiliary brake: engine exhaust valve brake
	Steering Gear		Power steering, hydraulic steering with power assistance
	Tire	Quantity	6 pcs with one spare tire
		Specifications	10.00R20
Transmission	Manual type,6 Forwards and 1 reverse
Cabin	Single row seat, Tiltable. It can accommodate three people. With air conditioner.
Engine	Brand		DONGFENG
	Fuel type		Diesel
	Power(kw)		177 kw
	Horsepower(HP)		180 HP
	Cylinder number		6
	Emission standard		Euro 4
Upper
Water tank	Capacity(cbm/tons)		14
	Tank material		Q235 carbon steel
	Thickness(mm)		4
Water pump	China local brand
	Suction Height		7M
Function	1, Front Side Rear Sprinkling width≥14m
	2, Water cannon range≥28m
Remarks	1. AM/FM radio
	2. 2pcs water hose.
	3. Color is optional

Water Truck Digram

14000L Water Sprinkler Truck For Transport Water Tank 0

Other types of water truck:

Working Diagram

Production Line for Water Tank Truck

Sales Service

①Pre-sales Service: Communicate with customers, analyze their needs.
②Sales Service: Provide professional technical solutions, recommend the right models accordingly.
③After-sales Service: For different products, we can quote the EXW, FOB, CFR or CIF price accordingly.

FAQ

Q1: What kinds of water bowser I can order from your company?
A: There are various sizes and types of water bowsers with different functions,you can contact us and tell your request.We will recommend you suitable product.

Q2:: Have you supplied water bowsers to any overseas companies?
A: Yes,with need of government and construction project,we offered water bowsers to many Africa and south-east Asian,south-American countries.

Q3 What about warranty?
A: Equipment warranty is 12 months from the date on which the equipment is applied successfully into operation, or 13 months from the date on which the equipment has been delivered, whichever comes first.

Q5: Where is your factory? How far from Shanghai to your factory?
A: Our factory is based in Suizhou city, Hubei province, China. Our overseas marketing office is in Wuhan city,Hubei Province.Wuhan is about two hours' plane and four hours' high speed train from Beijing,Shanghai or Guangzhou city,welcome to visit us for factory inspection.
